Azure Event Hubs Node

The Azure Event Hubs Node allows a workflow to publish a message to an Azure Event Hub.

Configuration

Configuration for the node is broken up into four sections …

Connection

First, choose where to send your message.

• Choose an Integration: Retrieves your Azure Event Hubs configuration from the selected Integration.

  • Integration: Choose which of your application’s Azure Event Hubs integrations you would like to publish the message on. The ID is templatable.

• Choose a Service Credential: Configure the Azure Event Hubs connection with an Azure service credential previously saved in WEGnology.

  • Credential Name Template: The name of the Azure service credential.
  • Host Name Template: The host name of the Azure Event Hub Namespace to which messages should be sent. This field is templatable.
  • Event Hub Name Template: The name of the event hub to send messages to. This field is templatable.

• Enter Connection String: Enter the credentials directly into the node fields. Both of these fields are templatable.

  • Connection String Template: The connection string scoped to either an event hub namespace, or to a specific event hub. In order to properly connect with WEGnology, the access policy associated with the connection string must have Send permission.
  • Event Hub Name Template: The name of the event hub to send messages to.

  Note: Integrations and service credentials are not accessible from Edge Workflows, so only direct configuration is available to them.

Message

Next, define the content of the message itself.

• Partition Key Template: Optionally, you may provide a partition key to send the message to a specific partition for data organization purposes.

• Message Data Method: Select the format of the message template:

  • String Template accepts a string template for the message - or a plain string.
  • Payload Path accepts a payload path for the message.
• Message Template / Payload Path: Enter the message data in the selected format.

User Properties

Optionally, you may include include some additional properties along with your message in the form of key/value pairs. There are three methods by which you may include the attributes:

• Individual Fields allows you to enter each key/value separately, with the key and the value both accepting string templates.
• JSON Template accepts an object of key/value pairs in one block. The object may not contain any nested properties, and Handlebars helpers may be used for either the keys or values.
• Payload Path accepts a payload path to an object of key/value pairs on your payload.

Result Path

Optionally, you can store the message response on the current payload by entering a payload path here. The value will be an object with the following properties:

• success: The value is true if the message was successfully sent, and false if the message failed to send.
• error: If the message failed to send, the result will include an error object with properties detailing why the sending failed.

Related Nodes

• Azure Event Hubs Trigger
